ZU2200

Ultra bright professional WUXGA laser projector

The high brightness ZU2200 professional laser projector fills a need for high-end installations, including the entertainment, exhibition, and digital signage markets. Part of Optoma’s Ultra Bright Series, this projector offers incredibly high brightness of 22,000 lumens as well as extreme flexibility with eight interchangeable lenses to meet the needs of even the most complex installations.

As part of the Optoma DuraCore laser line up, the Ultra Bright Series high-performance projectors feature 4K HDR compatibility, pure engine video processing and colour matching to produce visually striking, lifelike images with exceptional detail and high colour accuracy. Additionally, the ZU2200 achieves superior colour rendition through MultiColor Laser (MCL) technology.

Strong reliability is at the core of the Ultra Bright Series projectors, with 24/7 operation capabilities, up to 30,000 hours of laser lifetime, and an IP5X rating for optimal and dependable performance, even under more extreme conditions up to 122 degrees Fahrenheit / 50 degrees Celsius. With a robust metal chassis and modular design for easier maintenance, a multitude of connectivity options, and failsafe redundancy mode for instant source switching, the Ultra Bright Series projectors offer a solution for intricate installations, including multi-projector and dome projection applications.

Features

DuraCore

Industry leading lifetime is achieved using Optoma’s DuraCore technology. Implementing advanced laser diode cooling techniques and an innovative dust resistant design.

Constant brightness

Advanced light sensing technology allows the setting of brightness levels that will remain unchanged over time. Ideal for ensuruing constant brightness for fine tune installations

Constant power

Allows users to set the power levels to meet individual installation requirements. Power levels can be managed to obtain the brightest picture or longest light source life - or anywhere inbetween

HDBaseT™

Uncompromising, uncompressed Full HD video, audio, network and control commands all delivered on a single CAT- type cable capable up to 100 meters/328 feet without signal loss makes installation hassle-free. HDBaseT™ simplifies cabling requirements and reduces installation complexity saving both time and reducing costs.

Integrated warping and edge blending processor

Integrated warping and edge blending processor enables multiple projectors to be warped and blended without additional dedicated hardware, reducing the cost & complexity of installation. Warping and edge blending is configured using either the projectors on screen display or with PC software depending on model.

Compatible multi output graphics card with overlap function is required.*

Metal chassis with modular design

The modular metal chassis panels and quick release screws
make routine maintenance easier than ever before.

Wide temperature operating range

Suitable for various operating environments, the robust and
efficient cooling design enable the projectors to withstand an
ambient operating temperature range of 0~50°C

Full 3D

Optoma projectors can display true 3D content from almost any 3D source, including 3D compatible graphics cards, 3D broadcasting and the latest generation 3d media servers.

IP5X Dust resistant optical engine

Independently tested and certified to IEC standard 60529 with an IP5X dust resistance rating. Outstanding dust resistance combined with exceptional brightness ensures industry leading durability; paramount for 24/7 maintenance free operation in challenging environments.

Passive 3D compatibility

Passive 3D is now available on single chip DLP laser phosphor
projectors. Thanks to the high efficiency light output, these
models enable effective 3D solutions for operators to reduce
total cost of ownership.

Wired remote

The wired remote connection allows all aspects of the projector to be individually controlled without requiring a line-of-sight to the projector; invaluable when using multiple units during live events.

Redundant input with fast switching

The unique signal input detection function provides instant
source switching in the event of the failure of the signal source
device. This feature ensures an image never fails to display in
mission critical installations such as control rooms, live events
or other similar scenarios.

Auto focus (AF)

Providing a quick, hassle free and more convenient setup; You can enjoy a pin sharp image in a matter of seconds with the super fast camera based auto focus.

*Auto focus is compatible with image sizes up to 300"

Colour Management System

Display accurate lifelike colours to best match your viewing environment. This unique feature provides you with the flexibility to fine-tune the colour settings for optimal precision.

Auto Colour Uniformity

Providing a quick, hassle free and more convenient setup; You can enjoy acurate colour uniformity in a matter of seconds with the super fast camera based auto colour uniformity feature.

*The auto colour uniformity feature is compatible with image sizes up to 300"

LAN Control

The RJ45 port provides additional network controllability. Crestron RoomView, Extron’s IP Link, AMX dynamic device discovery and PJ-Link protocols are fully supported, allowing for any flexible networking solution.

Extreme Black

Extreme black enables the laser diodes to completly turn off when a full black image frame is detected. This feature is perfect for situations where a total image blackout is required.

Amazing colour

Optoma projectors provide reliable colour performance suitable for any content and environment. From accurate sRGB colours for lifelike images to vibrant punchy presentations. We have a display mode to specific meet your needs. Perfect for a range of graphic and video presentations.

Associated Accessories

Specification

Display technology

DLP

Resolution

WUXGA (1920x1200)

Brightness

22,000 lumens

Contrast ratio

2,000,000:1

Native aspect ratio

16:10

Aspect ratio - compatible

16:9,16:10

Keystone correction - horizontal

+/-20°

Keystone correction - vertical

+/-20°

Screen size

Dependent on lens

Lamp info

Light source type

DuraCore MultiColor Laser

LASER life

30,000 hours

Optical

Throw ratio

Dependent on lens

Projection distance

Dependent on lens

Lens options

BX-CTA11, 0.65~0.75:1BX-CTA18, 0.84~1.02:1BX-CTA19, 1.02~1.36:1BX-CTA20, 1.2~1.5:1BX-CTA21, 1.5~2.0:1BX-CTA22, 2.0~4.0:1BX-CTA23, 4.0~7.2:1BX-CTA27, 7.2~10.8:1

Connectivity

Connections

Inputs 1 x RS232, 1 x 3D sync, 1 x Wired remote, 1 x HDBaseT, 1 x DisplayPort, 2 x HDMI, 1 x VGA, 1 x DVI-D, 1 x 3G-SDIOutputs 1 x RS232, 1 x 3D sync, 1 x Wired remote, 1 x HDMI, 1 x 3G-SDIControl 1 x RJ45, 1 x USB-A service, 1 x 12V trigger

LAN - wireless networking

General

Noise level (min)

38dB

Noise level (max)

40dB

Full 3D

IP rating

IP5X

360° operation

Yes

Operating conditions
